Item | Unit | Value | Remarks | |
Working performance | Max. rated lifting capacity | kg | 55000 | |
Max. load moment of basic boom | kN.m | 1568 | ||
Max. load moment of main boom(fully extended) | kN.m | 940.8 | ||
Max. lifting height of main boom | m | 44 | These parameters do not include deflection of main boom and jib | |
Max. lifting height of jib | m | 60 | ||
Working speeds | Max. hoist rope speed(Main winch) | m/min | 135 | At 4th layer |
Max. hoist rope speed(Auxiliary winch) | m/min | 120 | At 2nd layer | |
Boom demrricking up time | s | 45 | ||
Boom telescoping out time | s | 95 | ||
Slewing speed | r/min | 0-2.2 | ||
Driving parameters | Max. height above sea level | m | 2000 | |
Max. driving speed | km/h | 74 | ||
Max. gradeability | % | 40 | ||
Min. turning diameter | m | ≤24 | ||
Min. ground clearance | mm | 260 | ||
Oil consumption per hundred kilometers | L | 40 | ||
Mass | Deadweight in driving condition | kg | 39000 | Excluded 1.5t auxiliary counterweight |
Complete vehicle kerb mass | kg | 38805 | ||
Front axle load | kg | 13000 | ||
Rear axle load | kg | 26000 | ||
Dimensions | Overall dimensions(L×W×H) | mm | 13530×2600×3700 | |
Outrigger spread(L) | m | 7.3 | ||
Outrigger spread(W) | m | Fully extended: 5.95, intermediately extended: 4.8 | ||
Tail slewing radius | mm | 3690 | ||
Main boom length | m | 11.2 - 44.0 | ||
Boom angle | ° | -2 - 80 | ||
jib length | m | 9.5, 16 | ||
Offset | ° | 0/15/30 | ||
