Model | ZZ1047D3414C145 | ||
Engine | Diesel 4-stoke Direct injection, 4-cylinder in line, Turbo-charging, Inner cooling. | ||
Model: | YN4100QBZL | YUNNEI | |
Engine power | 95hp/ 70kw | ||
Displacement(L): | 3.298liter | ||
Max torque: | 285NM@2000-2200rpm | ||
Bore/stoke: | 100mm/105mm | ||
Gear box | CNHTC | Max torque:360NM | |
Model: | WLY6T100 | ||
Speed: | 6speed, 1reverse | ||
Axle(front/rear) | |||
Front axle | 2T front steering axle, drum brake | ||
Tandem | 3.5T driving axle, drum brake, ratio: 5.375 | ||
Steering | LHD, RHD is optional | ||
Tyre | 6+1 spare tyre with rim | ||
7.00R16 radial tyre | |||
Suspension system: Strengthen heavy duty Leaf spring type | |||
Front/Rear | 11/9+7H | ||
Cargo body: | |||
Inside size of Body(mm): 4200x2050x1800 (Length x width x height) | |||
Overall dimension(mm): 5995x2100x3450 (Length x width x height) | |||
