Name | New HOWO TX 6×4 Dump Truck | |
Size (mm) | ||
Cab | TX flat roof cabin with A/C | |
Tires | 12.00R20, 10+1pcs | |
Axle | VGD95 front axle，MCP16ZG rear axle | |
Engine | Model | WP10.380E22, Weichai ,Euro2 , Diesel |
Engine power | 280KW (380HP) @ 2200rpm | |
Max torque | 1600 N.m @ 1500-1800rpm | |
Air intake type | turbo-charge and inter-cool | |
Alignment of cylinders | 6 cylinders in line | |
Fuel injection type | Direct injection | |
Compression ratio | 17: 1 | |
Bore * Stroke | 126x130mm | |
Gearbox | HW19710 gearbox with HW50 power take-off, 10 forward speeds + 2 reverse speeds | |
Steering | BOSCH | |
Fuel tank | 400L fuel tank | |
Suspension | Front and rear reinforced multi-leaf springs (11/11/12) | |
Main beam | Double layer frame (8+8/300) | |
Dumper box | 5600 x 2550 x 3500mm, bottom plate thickness is 8mm, side plate thickness is 6mm. Front lifting | |
